S-400-15 25A precio barato 400 vatios de salida única con CE caja de metal 400 w de conmutación fuente de alimentación modelo
|Ventas al por menor del volumen||1 piece|
|Último precio||US $43.64 / piece|
|Calificación del producto||0.0|
Shopping for a S-400-15 25A precio barato 400 vatios de salida única con CE caja de metal 400 w de conmutación fuente de alimentación modelo with low price? Read about features, types, and other must-know topics in our S-400-15 25A precio barato 400 vatios de salida única con CE caja de metal 400 w de conmutación fuente de alimentación modelo buying guide to make an informed choice. Order good S-400-15 25A precio barato 400 vatios de salida única con CE caja de metal 400 w de conmutación fuente de alimentación modelo Look for the S-400-15 25A precio barato 400 vatios de salida única con CE caja de metal 400 w de conmutación fuente de alimentación modelo package that is good for you. Make a price comparison, discount promo, or free sending before ordering.
Please make sure the input voltage, output voltage and current in item specs when placing orders. Or we\\\'ll arrange the one as the item specs says.
Model S-400-9 S-400-12 S-400-13.5 S-400-15 S-400-24 S-400-27 S-400-48
DC Voltage 9V 12V 13.5V 15V 24V 27V 48V
Voltage Tolerance 1% 1% 1% 1% 1% 1% 1%
Rated Current 43A 33A 28A 25A 16A 15A 8.3A
Current Range 0-43A 0-33A 0-28A 0-25A 0-16A 0-15A 0-8.3A
Rated Power 387W 348W 348.3W 348W 350.4W 351W 350.4W
Ripple & Noise 150 mVp-p 150 mVp-p 150 mVp-p 150 mVp-p 150 mVp-p 200 mVp-p 240 mVp-p
Range 10% -16%,+10% -12%,+11% -10%,+20% -16%,+10% -4%,+18% -15%,+17%
Setup,Rise,Hold Time: 200ms,50ms,20ms at full load
Voltage Range 170-264VAC 47~63 Hz;selected by switch 254~370VDC
AC Current 6.5A/115 V 4A/ 230 V
Efficiency 73%(S-400-5); 76%(S-400-7.5); 74%(S-400-12); 79%(S-400-13.5);
78%(S-400-15); 81%(S-400-24); 82%(S-400-27); 83%(S-400-48);
Inrush Current Cold start 50A/115V50A/230V
Leakage Current < 3.5 mA/240VAC
Over Load 105%~135%
Protection type: Fold back current limiting, recovers automatically after fault condition is removed.
Over Voltage 115%~135%
Protection type: hiccup mode, recovers automatically after fault condition is removed.
Over Temp. RT355C FAN ON,45C FAN OFF,80C output shutdown (5~7.5V)
RT365C FAN ON,55C FAN OFF,80C output shutdown (12~15V)
RT370C FAN ON,60C FAN OFF,85C output shutdown (24~48V)
Working Temp., Humidity -10C~+60C;20%~90 %RH
Storage Temp., Humidity -20C~+85C;10%~95 %RH
Vibration 10~500Hz,2G 10min./1cycl, period for 60 min, each along X, Y, Z, axes
Withstand Voltage I/P-O/P: 1.5KVACI/P-FG: 1.5KVACO/P-FG: 0.5KVAC
Isolation Resistance I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
Safety Standard Design refer to UL1012
EMC Standard Design refer to FCC Part15 J Conduction Class B
Packing:11pcs/14.42kg/box.According to your order,we can provide different cartons for you.
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25C of ambient temperature.
2.Ripple & noise are measured at 20MHz of bandwidth by using a 12twisted pair-wire terminated with a 0.1 &47
3.Tolerance: includes set up tolerance, line regulation and load regulation
MingWei switching power supply factory is a set design, development, production in one of the high-tech professional manufacturers, the region is the first company to introduce Taiwan manufacturer of switch power supply technology, building in May 2001.
- Custom Product Design
- Profession in export service from Maker Electric
- High quality Product, Affordable Price
Notes on choosing a switching power supply?
To increase the reliability of the S.P.S., we suggest users choose a unit that has a rating of 30% more power than actual need. For example, if the system needs a 100W source, we suggest that users choose a S.P.S. with 130W of output power or more. By doing this, you can effectively boost the reliability of the S.P.S. in your system.Make sure that the model qualifies for the safety standards and EMC regulations you need.
- What are switching power supplies?
- Switching power supplies input a commercial AC power supply (such as 110 VAC or 220 VAC), uses a high-speed semiconductor switching process to convert the input to high-frequency electric power, and yields a direct current (such as 24 VDC).
- What about production process of switching power supply?
